Kablosuz Access Point Cloud-managed outdoor APs

Ruijie RG-AP680-L Wi-Fi 6 Çift Bant Dış Ortam Access Point

ModelRG-AP680-L

Ruijie RG-AP680-L access point: Industrial-grade product design, IP68 rating, Operating temperature: –40°C to +65°C, High-power omnidirectional antennas with 360° coverage to every corner, Upgraded to Wi-Fi 6, a combined data rate of up to 2.976 Gbps, Ruijie cloud management, intelligent opt.

Kablosuz standart: Wi-Fi 6

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

Industrial-grade product design, IP68 rating, Operating temperature: –40°C to +65°C
High-power omnidirectional antennas with 360° coverage to every corner
Upgraded to Wi-Fi 6, a combined data rate of up to 2.976 Gbps
Ruijie cloud management, intelligent optimization

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Donanım Özellikleri 16 satır

Unit dimensions(W x D x H)	251 mm x 168 mm x 64 mm (9.88 in. x 6.61 in. x 2.52 in.)
Shipping dimensions(W x D x H)	415 mm x 242 mm x 337 mm (16.34 in. x 9.53 in. x 13.27 in.)
Cihaz Ağırlığı	Main unit: 1.12 kg (2.47 lbs); Mounting bracket: 0.9 kg (1.98 lbs)
Kutulu Ağırlık	6.43 kg (14.18 lbs)
Montaj	Ceiling/Pole-mount (a mounting bracket is delivered with the main unit)
Radyo Tasarımı	Dual-radio and four spatial streams:; Radio 1: 2.4 GHz, two spatial streams, 2x2 MU-MIMO; Radio 2: 5 GHz, two spatial streams, 2x2 MU-MIMO
Çalışma Frekansları	Radio 1: 802.11b/g/n/ax; 2.400 GHz to 2.4835 GHz, channels 1 to 13; Radio 2: 802.11a/n/ac/ax; 5.150 GHz to 5.250 GHz, U-NII-1, channels 36, 40, 44, and 48; 5.250 GHz to 5.350 GHz, U-NII-2A, channels 52, 56, 60, and 64; 5.470 GHz to 5.725 GHz, U-NII-2C, channels 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, and 140; 5.725 GHz to 5.850 GHz, U-NII-3/ISM, channels 149, 153, 157, 161, and 165; Note: Available frequency bands may vary with countries or regions. To use the above-mentioned frequency
Data rates	Combined peak data rate: 2.976 Gbps; Radio 1: 2.4 GHz, 574 Mbps; Two spatial stream Single User (SU) MIMO for up to 574 Mbps wireless data rate to individual 2SS HE40 802.11ax client devices (maximum); Two spatial stream Single User (SU) MIMO for up to 287 Mbps wireless data rate to individual 2SS HE20 802.11ax client devices (typical); Radio 2: 5 GHz, 2.402 Gbps; Two spatial stream Single User (SU) MIMO for up to 2.402 Gbps wireless data rate to individual 2SS HE160 802.11ax client devices (max
Data rate set	The following 802.11-compliant data rates in Mbps are supported:; 2.4 GHz radio; 802.11b: 1, 2, 5.5, 11; 802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54; 802.11n: 6.5 to 300 (MCS0 to MCS15, HT20 to HT40); 802.11ac: 6.5 to 400 (MCS0 to MCS9, NSS = 1 to 2,VHT20 to VHT40); 802.11ax: 8.6 to 574 (MCS0 to MCS11, NSS = 1 to 2, HE20 to HE40); 5 GHz radio; 802.11a: 6, 9, 12, 18, 24, 36, 48, 54; 802.11ac: 6.5 to 1733 (MCS0 to MCS9, NSS = 1 to 2,VHT20 to VHT160); 802.11ax: 8.6 to 2,402 (MCS0 to MCS11,
Packet aggregation	802.11n/ac/ax : A-MPDU and A-MSDU
Anten Tipi	Built-in omnidirectional antennas (two 2.4 GHz antennas and two 5 GHz antennas)
Anten Kazancı	2.4 GHz radio: 3.5 dBi; 5 GHz radio: 5.5 dBi
Maks. Yayın Gücü	2.4 GHz radio: 28 dBm (25 dBm per chain); 5 GHz radio: 28 dBm (25 dBm per chain); Note: The transmit power is limited by local regulatory requirements. For details, see WLAN Country or Region Codes and Channel Compliance.; Thailand; 2.400 GHz to 2.4835 GHz: 20 dBm; 5.470 GHz to 5.725 GHz: 30 dBm; 5.725 GHz to 5.825 GHz: 30 dBm; Peru; 2.400 GHz to 2.4835 GHz: EIRP ≤ 36dBm; 5.150 GHz to 5.250 GHz: EIRP ≤ 23dBm; 5.250 GHz to 5.350 GHz: EIRP ≤ 30dBm; 5.470 GHz to 5.725 GHz: EIRP ≤ 30dBm; Egypt; 2.40
Power increment	Configurable in increments of 1 dBm
Radio technologies	802.11b: Direct-Sequence Spread-Spectrum (DSSS); 802.11a/g/n/ac: Orthogonal Frequency-Division Multiplexing (OFDM); 802.11ax: Orthogonal Frequency Division Multiple Access (OFDMA)
Modulation types	802.11b: BPSK, QPSK, CCK; 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM; 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM; 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM

Wi-Fi Radio Frequency Performance 17 satır

Frequency Band and Protocol	Data Rate
2.4 GHz 802.11b	1 Mbps; 2 Mbps; 5.5 Mbps; 11 Mbps
2.4 GHz 802.11g	6 Mbps; 24 Mbps; 36 Mbps; 54 Mbps
2.4 GHz 802.11n (HT20)	MCS0; MCS7
2.4 GHz 802.11n (HT40)	MCS0; MCS7
2.4 GHz 802.11ax (HE20)	MCS0; MCS11
2.4 GHz 802.11ax (HE40)	MCS0; MCS11
5 GHz 802.11a	6 Mbps; 24 Mbps; 36 Mbps; 54 Mbps
5 GHz 802.11n (HT20)	MCS0; MCS7
5 GHz 802.11n (HT40)	MCS0; MCS7
5 GHz 802.11ac (VHT20)	MCS0; MCS9
5 GHz 802.11ac (VHT40)	MCS0; MCS9
5 GHz 802.11ac (VHT80)	MCS0; MCS9
5 GHz 802.11ax (HE20)	MCS0; MCS11
5 GHz 802.11ax (HE40)	MCS0; MCS11
5 GHz 802.11ax (HE80)	MCS0; MCS11
5 GHz 802.11ax (HE160)	MCS0; MCS11

Bluetooth Radio 5 satır

Bluetooth	Bluetooth 5.0; iBeacon Bluetooth, applied to Bluetooth locating and Bluetooth applications
Anten Tipi	Integrated omnidirectional antenna
Maks. Anten Kazancı	5 dBi
Maks. Yayın Gücü	10 dBm
Alıcı Hassasiyeti	-88 dBm (@BLE)

Ports Specifications 4 satır

Sabit Servis Portları	1 x 10/100/1000BASE-T port, in compliance with IEEE 802.3af/802.3at standard; 1 x 1GE SFP port
Sabit Yönetim Portu	1 x RJ45 console port (serial console port)
Status LED	1 x multi-color system status LED; 3 x single-color RSSI LEDs
Buton	1 x Reset button; Press the button for shorter than 2 seconds. Then the device restarts.; Press the button for longer than 5 seconds. Then the device restores to factory settings.

Güç Kaynağı ve Tüketim 2 satır

Input power supply	The AP supports the following two power supply modes:; 48 V DC/0.35 A power input over DC connector: The DC connector accepts 2.0 mm/6.3 mm center-positive circular plug. A DC power adapter needs to be purchased independently.; PoE input over ETH/PoE: The power source equipment (PSE) complies with IEEE 802.3af/at standard (PoE/PoE+).; Note:; If both DC power and PoE are available, DC power is preferred.
Overall power consumption	Maximum power consumption: 12.95 W; DC powered: 12.95 W; PoE powered (802.3af): 12.95 W; PoE+ powered (802.3at): 12.95 W; PoE++ powered (802.3bt): 12.95 W; Idle mode: 6.0 W

Input power supply

The AP supports the following two power supply modes:; 48 V DC/0.35 A power input over DC connector: The DC connector accepts 2.0 mm/6.3 mm center-positive circular plug. A DC power adapter needs to be purchased independently.; PoE input over ETH/PoE: The power source equipment (PSE) complies with IEEE 802.3af/at standard (PoE/PoE+).; Note:; If both DC power and PoE are available, DC power is preferred.

Overall power consumption

Maximum power consumption: 12.95 W; DC powered: 12.95 W; PoE powered (802.3af): 12.95 W; PoE+ powered (802.3at): 12.95 W; PoE++ powered (802.3bt): 12.95 W; Idle mode: 6.0 W

Ortam ve Güvenilirlik 4 satır

Sıcaklık	Operating temperature: –40°C to +65°C (–40°F to +149°F); Storage temperature: –40°C to +85°C (–40°F to +185°F); Note: At an altitude in the range of 3,000–5,000 m (9,842.52–16,404.20 ft.), every time the altitude increases by 220 m (722 ft.), the maximum temperature decreases by 1°C (1.8°F).
Nem	Operating humidity: 0% RH to 100% RH (non-condensing); Storage humidity: 0% RH to 100% RH (non-condensing)
IP Koruma Sınıfı	IP68
MTBF	> 250,000 hours

Uyumluluk 4 satır

Security standards	IEC 62368-1; EN 62368-1; EN 60950-22
Cyber security standards	EN 18031-1; EN 18031-2
EMC Standartları	EN 55032; EN 55035; EN IEC 61000-3-2; EN 61000-3-3; EN 301 489-1; EN 301 489-3; EN 301 489-17
Radio frequency standards	EN 300328; EN 301 893; EN 300 440; EN 62311; EN IEC 62311; EN 50665; FCC Part 15

Yazılım Özellikleri 13 satır

Applicable software version	RGOS11.9(6)W3B3 or later
Recommended maximum number of active devices per AP	120
Maximum number of associated clients	1024; Note; The number of associated clients varies according to the environment.
Maximum number of BSSIDs	32 (up to 16 BSSIDs per radio)
STA management	SSID hiding; Each SSID can be configured with the authentication mode, encryption mechanism, and VLAN attributes independently.; Remote intelligent perception technology (RIPT); Intelligent client identification technology; Intelligent load balancing based on the STA quantity or traffic
STA limiting	SSID-based STA limiting; Radio-based STA limiting
Bandwidth limiting	STA/SSID/AP-based rate limiting
Wireless roaming	Layer 2 and Layer 3 roaming
Authentication and encryption	Remote Authentication Dial-In User Service (RADIUS); PSK, web, 802.1X, WPA, WPA2, and WPA3 authentication; SMS authentication (used with the RG-WS series wireless access controller); MAB authentication (used with the RG-WS series wireless access controller); WEP (64/128 bits), WPA-Personal, WPA-Enterprise, WPA2-Personal, WPA2-Enterprise, WPA3-Personal (WPA2/WPA3 transition mode), WPA3-Enterprise (CCMP), WPA3-OWE
Data frame filtering	Allowlist, static blocklist, and dynamic blocklist
ACL	Dynamic ACL assignment
CPP	Destekleniyor
NFPP	Destekleniyor

Routing and Switching 5 satır

IP Servisleri	Static IPv4 address and DHCP-assigned IPv4 address; NAT, FTP ALG, DNS ALG
Multicast	Multicast-to-unicast conversion
IPv6 basics	IPv6 addressing, Neighbor Discovery (ND), ICMPv6, IPv6 ping; IPv6 DHCP client
IP Yönlendirme	IPv4/IPv6 static routing
VPN	PPPoE client; IPsec VPN, up to four IPsec tunnels

Yönetim 4 satır

Ağ Yönetimi	Fault inspection and alarm; Information statistics and logging; SNMPv1/v2c/v3; NTP Server and NTP Client
Network management platform	Ruijie Cloud; Web-based management (Eweb)
User access management	Console, Telnet, SSH, SNMP and TFTP-based management
Fat/Fit/Cloud mode switchover	When the AP works in Fit mode, it can be switched to Fat mode through an AC.; When the AP works in Fat mode, it can be switched to Fit mode through the console port or Telnet.; When the AP works in Cloud mode, it can be managed through Ruijie Cloud.

Temel Özellikler 7 satır

Wireless Protocols	802.11a/b/g/n/ac/ax
Veri Hızı	Combined peak data rate:2.4 GHz + 5 GHz, 2.976 Gbps
Maks. Güç Tüketimi	12.95 W
External Power Supply	Hayır
Çalışma Sıcaklığı	–40°C to +65°C (–40°F to +149°F)
Boyutlar (G x D x Y)	251 mm x 168 mm x 64 mm (9.88 in. x 6.61 in. x 2.52 in.)
Garanti	3 Years

Genel bakış

Ruijie RG-AP680-L kullanım alanları ve özellikleri.

Outdoor scenarios in general education, energy, business, government, and healthcare sectors

Designed for Beach Ruijie Cloud Managed Series Outdoor AP RG-AP680-L

Port

Dimensions

Max. Data Rate 2.976 Gbps

4 Spatial Streams

IP68 Rating

DC/PoE Power Supply

Free Cloud Management

Industrial-Grade Product Design Ensuring Stable Running in Harsh Environments

Corrosion Protection

6 kV Lightning Protection

Wide Temperature Range

Comply with salt spray prevention standards, ensuring stable running in saline, warm and humid environment.

IP68 rating protection against dust and water, avoiding liquid and sand intrusion.

Built-in high-standard lightning protectors, defending against 6 kV surge and ensuring stable running in bad weather such as thunderstorms.

Operating in the range of –40°C to +65°C, adapting to clod weather in the northern regions.

Omnidirectional Antennas with 360° Coverage to Every Corner

Equipped with 28 dBm omnidirectional antennas with high transmit power Extending coverage to every corner within 360° and up to 300 m in radius Good signal coverage for STAs around the AP (including the rear side) Applicable to outdoor environments where STAs are dispersed

*The maximum range of Wi-Fi coverage is calculated based on field tests. The real transmission range may vary, according to the environment, receiving device, etc.

Wi-Fi 6 AX3000

Achieving a combined data rate of up to 2.976 Gbps

High Concurrency OFDMA and MU-MIMO are introduced to ensure stable access of multiple STAs

Low Latency OFDMA is applied to transmit data to multiple STAs simultaneously. The latency is as low as 20 ms.

High Security The next-generation wireless encryption protocol WPA3 greatly improves the

High Speed With 1024-QAM modulation, the data transmission rate is 25% higher than 802.11ac.

Cloud, Make Your Business Easy

Cloud portal authentication
Remote Wi-Fi management
Wireless intelligent optimization

Nerelerde kullanılır?

Ofis, otel, okul ve mağazalarda kesintisiz kablosuz kapsama ve dolaşım (roaming) için tavan veya duvar montajıyla kullanılır.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Product DatasheetPDF · RG-AP680-L

Sık sorulanlar

RG-AP680-L hakkında kısa yanıtlar.

RG-AP680-L fiyatı ne kadar?

RG-AP680-L için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
