Hikvision
Hikvision DS-6910UDI Video Decoder
Model
DS-6910UDIHikvision DS-6910UDI video decoder: DS-6901UDI provides HDMI, VGA, and BNC output interfaces., DS-6904UDI, DS-6908UDI, DS-6910UDI, DS-6912UDI, DS-6916UDI provide HDMI (adaptable to DVI-D) and BNC output interfaces., Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for even interface).
Fiyat ve stok bilgisi alınAynı gün dönüş
Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.
Distribütör garantili
81 ile sevkiyat
Teknik destek
- DS-6901UDI provides HDMI, VGA, and BNC output interfaces.
- DS-6904UDI, DS-6908UDI, DS-6910UDI, DS-6912UDI, DS-6916UDI provide HDMI (adaptable to DVI-D) and BNC output interfaces.
- Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for even interface).
- Up to 16-ch decoding at 12 MP resolution (DS-6916UDI).
- H.265+/H.265, H.264+/H.264, MPEG4 and MJPEG video compression.
- PS, RTP, TS, ES, HIK encapsulation formats.
- Three encoding levels: baseline, main, and high-profile.
- G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compression.
Teknik özellikler
Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.
Video/Ses Girişi 1 satır
| VGA and DVI-I input | WSXGA: 1680×1050/60Hz; WXGA: 1440×900/60Hz; WXGA: 1280×800/60Hz, 1366×768/60Hz,; 1080p: 1920 × 1080@50/60Hz; UXGA: 1600 × 1200@60Hz; XVGA: 1280 × 960@60Hz; 720p: 1280 × 720@50Hz/60Hz; SXGA: 1280 × 1024@60Hz; XGA: 1024 × 768@60Hz |
|---|
Video/Ses Çıkışı 2 satır
| HDMI Çıkışı | 10-ch; 4K: 3840 × 2160@30Hz ( for odd interface only); 1080p: 1920 × 1080@50/60Hz; WSXGA: 1680×1050/60Hz; UXGA: 1600 × 1200@60Hz (for odd interface only); 720p: 1280 × 720@50Hz/60Hz; SXGA: 1280 × 1024@60Hz; XGA: 1024 × 768@60Hz |
|---|---|
| BNC output | 5-ch, 2 DB 15 |
Audio/Video decoding 4 satır
| Decoding resolution | Up to 12MP |
|---|---|
| Decoding channel | 80-ch |
| Kod Çözme Kapasitesi | 12MP@20fps: 10-ch; 8MP@30fps: 20-ch; 5MP@30fps: 30-ch; 3MP@30fps: 50-ch; 1080p@30fps: 80-ch |
| Split screen | 1/4/6/8/9/12/16/25/36 |
Harici Arayüz 7 satır
| Ağ Arayüzü | 2, 10/100/1000 Mbps self-adaptive management network interface; 2, 10/100/1000 Mbps self-adaptive Ethernet interface; 16, 10M/100 Mbps self-adaptive Ethernet interface |
|---|---|
| Seri Arayüz | 1 RS-232 (RJ45), 1 RS-485 |
| Two-way audio in | 1-ch, 3.5 mm connector (2.0 Vp-p, 1 KΩ) |
| Two-way audio out | 1-ch, 3.5 mm connector (2.0 Vp-p, 1 KΩ) |
| Ses Çıkışı | 16-ch, 2 DB 15 |
| Alarm Girişi | 8 |
| Alarm Çıkışı | 8 |
Genel 6 satır
| Güç Kaynağı | 100 to 240 VAC |
|---|---|
| Güç Tüketimi | ≤ 108 W |
| Çalışma Sıcaklığı | -10 °C to +55 °C (14 °F to 131 °F) |
| Çalışma Nemi | 10% to 90% |
| Boyutlar (G x D x Y) | 440 × 311 × 80 mm (17.32 × 12.24 × 3.15 inch) |
| Ağırlık | ≤ 6.4 kg (14.11 lb) |
Genel bakış
Hikvision DS-6910UDI kullanım alanları ve özellikleri.
Tüm özellikler
- DS-6901UDI provides HDMI, VGA, and BNC output interfaces.
- DS-6904UDI, DS-6908UDI, DS-6910UDI, DS-6912UDI, DS-6916UDI provide HDMI (adaptable to DVI-D) and BNC output interfaces.
- Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for even interface).
- Up to 16-ch decoding at 12 MP resolution (DS-6916UDI).
- H.265+/H.265, H.264+/H.264, MPEG4 and MJPEG video compression.
- PS, RTP, TS, ES, HIK encapsulation formats.
- Three encoding levels: baseline, main, and high-profile.
- G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compression.
- Two decoding modes: active decoding and passive decoding.
- Remote video files’ decoding output.
- Supports window opening and window roaming.
- Supports multi-screen control with PC installed with RSC server.
- Supports Wi-Fi module access to display the signal from IOS/Android mobile phone or pad on video wall.
- Wi-Fi can be enabled via the Web browser or client software. You can get stream and decode the video on the video wall when Wi-Fi is enabled if no wired network can be accessed.
- Gets stream and decodes via URL and RTSP from encoding devices.
- Displays the decoded video stream on the video wall by directly linking cameras or by stream media forwarding.
- You can configure what the video wall show when decoding ends and streaming fails via the Web browser and client software.
- Configurable LED width and height parameters when the LED is connected.
- Regular and irregular virtual screen configurable to display multiple signal sources and get rid of the restriction of physical screen.
- Accessible by thermal network camera and you can view the temperature measurement, dynamic fire source detection, ship detection and VCA information in live view and playback.
- You can enable or disable the smart information for the thermal network camera.
- Remote PTZ control via transparent channel.
- Two-way audio.
- Port aggregation technology (Ethernet Channel).
Dokümanlar
Veri sayfası ve kullanım kılavuzları.
Sık sorulanlar
DS-6910UDI hakkında kısa yanıtlar.
DS-6910UDI fiyatı ne kadar?
DS-6910UDI için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
Hızlı teklif
Formu doldurun, DS-6910UDI için fiyat ve teslim süresini iletelim.
